Shenzhen Dstar Machine Co.,ltd    E-mail:dstar@printing-machine.com
  |

Pad printer/Machines/6 color pad printer/

6 color pad printer DX-M6S

Model:DX-M6S

Printing color:6 color

Printing plate size:100*200mm

Ink scrapping:open ink well

MOQ:1 Unit

H.S code:84431980.00

N.W:280 kgs

Machine size:L100*W96*H150cm

Air supply:5-7 bar

Voltage:AC110V or 220V

  • Product Detail
  • Why DSTAR
  • FAQs
  • Packing & Delivery
  • Videos

Pad printing machine(also called tampo printing machine) is a printing process that can transfer a 2D image onto a 3D object. This is accomplished using an indirect offset (gravure) printing process that involves an image being transferred from the cliché via a silicone pad onto a substrate.

DX-M6S pad printer

  • DX is short name of our company
  • M is one of the pad printer series(MINI,P,S,M,L)
  • 6 mean 6 color
  • S mean Shuttle

Technical parameters

Model:DX-M6S (open inkwell system)
Standard printing plate size:10*100*200mm
Printing speed:350 times/hr
Air pressure:5-7 bar
N.W:280 kgs
Machine dimension:L100*W96*H150 cm
Packing:wooden case

Pad printer consumables

  • Pad printing plate
  • Silicone pad
  • Pad printing ink and ink solvent
  • Work piece fixture
  • Ink blade(for open ink well system)
  • Sealed ink cup (for ink cup system)

pad printing samplePad printing samples

  • Stationery industry printing
  • Textile printing
  • Medical supplies printing
  • Hardware printing
  • Electronic printing
  • Toys printing
  • Packing printing
  • Glass products printing

Difference between open ink well and sealed ink cup

Open ink well system

Open ink well systems, the older method of pad printing, used an ink trough for the ink supply, which was located behind the printing plate. A flood bar pushed a pool of ink over the plate, and a doctor blade removes the ink from the plate surface, leaving ink on the etched artwork area ready for the pad to pick up.

Sealed ink cup system

Sealed ink cup systems employ a sealed container which acts as the ink supply, flood bar and doctor blade all at the same time. A ceramic ring or tungsten ring with a highly polished working edge provides the seal against the printing plate.

open ink well and sealed ink cup



  Shenzhen Dstar Machine Co.,ltd  is committed to providing customers with more efficient and higher-quality mechanical products. We have reached long-term cooperative relationships with many Fortune 500 companies and industry benchmark companies. Keeping pace with the times and continuous innovation are the foundation for our long-term development. Many machines are the first in the industry and are favored by many customers, such as automatic pvc ball printing machine,automatic bottle cap printing machine,automatic bottle screen printer,automatic label printing machine…

  Being one of the professional cosmetics suppliers, our raw material was selected from global range, applying top-quality international standard as quality control. We devote to be a world-class quality manufacturer for customers.

1.how to place order with your company?

    please send online inquiry.Then our sales will reply offer to you. If customer agree with offers,companies will sign sales contract. Next,the buyer shall fulfill payment obiligation,dstar machine will start order production.

2.can you print samples for checking quality?

    Yes,we can

3. is there operation training?

    Yes,we provide free training in our workshop.

4. how long warranty of the machine?

    1 year+lifelong technical supports

5. which payment item do you accept?

     L/C(100% irrevocable at sight)   or  T/T(30%deposit+70% balance before shipping)

Sea shipping port:Shenzhen,Hongkong

Air shipping port:Shenzhe,Guangzhou,Hongkong

Door to door express:DHL,TNT,FedEx,UPS
